Olympus Epoch XT Ultrasonic Flaw Detector For Sale

Olympus Epoch XT Ultrasonic Flaw Detector

Olympus EPOCH XT Ultrasonic Flaw Detector is designed for great inspection flexibility and for use in extreme environments. It combines a multitude of enhanced flaw detection and measurement features, a bright multi-color LCD, versatile battery options, powerful data management, and numerous software features in a compact unit with a sealed case designed to meet IP67 requirements.

Features Epoch XT

• EN 12668-1 compliant
• Tested for Explosive Atmoshpere, Vibration and Shock
• IP67. Designed to meet IP67 requirements. Sealed to withstand harsh environments
• Dynamic DAC/TVG Standard
  • Dynamic DAC curves
  • Custom warning levels
  • Meets ASME and JIS requirements
  • Advanced TVG Table allows customized TVG setups
• Multiple Battery Options – can be used with Lithium Ion, NiMH, or C-Cells
• Host USB Port for direct printing and storage to USB drives
• Client USB Port for PC communication
• “PerfectSquare™ Technology”: Pulse is electronically controlled on both the leading and trailing edges to maximize transducer performance and near surface resolution.
• PRF adjustable from 10 Hz to 1 kHz in 10 Hz increments.
• All measurements are taken “single shot”.
• Powerful alphanumeric datalogger
  • Corrosion thickness gage file types can be set up onboard
  • Simple incremental files
• Multi-color LCD display
• Lightweight – 4.7 lbs (2.1 kg)

New Direct-Acess Keypad
Logical color-coded key organization
Direct access to important instrument set-up parameters.
Direct entry of alphanumeric characters
Five customizable function keys allow the operator to quickly select preset values
Available in English, International Symbols, Japanese or Chinese
