Topcon MR-2 Modular GNSS Receiver

Tracking every available signal from all  the current and planned constellations is made possible by Topcon’s patented Universal Tracking Channel technology, thus ensuring that your investment is secure for today and into the future. Available in single or dual antenna input models.

Whether needing a modular mobile RTK base station, a receiver for marine navigation, or a positioning device for mobile mapping, the MR-2 by Topcon is your versatile solution. It is built for harsh environments, offering IP67 dust and water protection as well as a superior level of vibration and shock tolerance (MIL spec). Flexible communication interfaces make it easy to integrate into a myriad of applications.

Accuracy
RTK (L1+L2)
H: 5 mm + 0.5ppm (x baseline length)
V: 10 mm + 0.8ppm (x baseline length)
Fast Static (L1+L2)
H: 3 mm + 0.5ppm (x baseline length) (x baseline length)
V: 5 mm + 0.8ppm (x baseline length)
DGPS: H: 0.3m, V: 0.5m
SBAS: H: 0.8m, V: 1.2m
Heading: Heading 0.3º/D, where D is the inter-antenna distance in meters
Inclination: 0.2º/D (Where D is the inter-antenna distance in meters)
Velocity: 0.02 m/sec
Time: 30 nsec
